| FEATURES |
| ● Capable of measuring earth resistance and earth voltage. ● 2mA measuring current permits the testing of earth resistance without tripping earth leakage current breakers in the circuit under test. ● In addition to facilitating for precision measurement, test leads for simplified two-wire measuring system also are supplied as standard accessories. ● Battery operated. ● Battery life indicator. ● Calibration performed with supplied test leads. |
| SPECIFICATIONS |
| Measuring ranges | Earth resistance 0-12Ω / 0-120Ω / 0-1200Ω Earth voltage 0-30 Vac (40-500Hz) |
| Accuracy | Earth resistance ±3% of full scale Earth voltage ±2.5% of full scale |
| Measuring system | Earth resistance by constant current inverter 820 Hz, 2mA approx. |
| Open circuit indication |
LED will be unlit |
| Dimensions | 175(L) × 85(W) × 75(D)mm |
| Weight (battery included) |
Approx. 600g |
| Power source | 1.5V (AA) × 8 |
| Safety standards | EN 61010-1 CAT IV 30V EN 61326-1 |
